Eppendorf Repeater plus - Manual (Page 8)

Multipette® plus · Repeater® plus — Operating manual
8
4.2 Insert Combitip
1. If using 25 mL or 50 mL Combitips, connect the adapter to the
Combitip outside the Multipette plus/Repeater plus.
2. Slide the filling lever right to the bottom and hold it there.
3. Push the Combitip from below into the Multipette plus /
Repeater plus and, in doing so, hold the filling lever slid
downwards. Or insert the Combitip and then push the filling lever
downward.
4.3 Select volume

Turn the volume selection wheel until it locks into the desired
position.
The volume selection wheel has 20 positions. They are indicated with
the figures 1 to 10. Positions between these numbers, and
position 0.5, are indicated with a spot.
4.3.1 Filling Combitip and reverse stroke
1. Immerse the tip of the Combitip in the liquid.
2. Slowly and uniformly push the filling lever up to the stop.
The display is blinking, the Multipette plus/Repeater plus is not yet
ready for operation.
NOTICE!
NOTICE! Damage to property due to incorrect
insertion of the Combitip.
 For Multipette plus/Repeater plus manufactured before
12/15/2009: Do not press the ejection keys when a
Combitip is inserted.
Hint!
When setting small volumes (position 5 and below), the
operating path of the dosage lever is reduced automati-
cally. The dosage lever changes its position when the vol-
ume selection wheel is turned.
You cannot turn the volume selection wheel beyond
position 10.
Do not turn the volume selection wheel beyond 10 or 0.5.
Turn the volume wheel back to its initial position.
1 2 3
Multipette
® plus
