Multipette® plus · Repeater® plus — Operating manual
4
Fig. 1: Multipette plus/Repeater plus
2.2 Combitips advanced
A supply of liquid is aspirated into the Combitip advanced and then
dispensed step by step.
The built-in electronics automatically recognize
•
the Combitip advanced inserted and
•
the position of the volume selection dial,
and the current dispensing volume appears in the display.
Nine Combitips advanced with a variety of filling volumes are
available for single use (see Choose Combitip on p. 7). The
Combitips advanced 25 mL and 50 mL can only be used in
combination with an adapter. The adapter is a wear part.
For each Combitip advanced, you can use the volume selection dial
to set 20 different volumes.
The smallest volume can be dispensed up to a max. of 100 times and
the largest volume a max. of 5 times.
Fig. 2: Combitip advanced
2.3 Combitips plus
Multipette plus/Repeater plus can also be used with Combitips plus
(predecessor model).
1 Volume selection dial 2 Position indicator
3 Battery compartment 4 Digital display
5 Dispensing lever 6 Filling lever
7 Ejection keys 8 Serial number
1 Dispensing volume with the
manual dispenser at selection
dial position 1
2 Graduation
3 US patent numbers 4 Maximum volume
5 Color code 6 Coding
7 Piston
1=100µL ^
5 mL
US-PAT.No. 5.620,660
1 2 3 4 5 6 7
