Multipette® plus · Repeater® plus — Operating manual
13
7Technical data
7 Technical data
The data is valid for the following test conditions, in accordance with
ISO 8655:
8Ordering Information
8 Ordering Information
Combitip
advanced
Testing 
volume
Error limits
Error
Systematic
error
Random
error
± % ± μL ± % ± μL
0.1 mL
white 2 μL ±1.6 ±0.032 ±3.0 ±0.06
20 μL ±1.0 ±0.2 ±2.0 ±0.4
0.2 mL
light blue 4 μL ±1.3 ±0.052 ±2.0 ±0.08
40 μL ±0.8 ±0.32 ±1.5 ±0.6
0.5 mL
violet 10 μL ±0.9 ±0.09 ±1.5 ±0.15
100 μL ±0.8 ±0.8 ±0.6 ±0.6
1 mL
yellow 20 μL ±0.9 ±0.18 ±0.9 ±0.18
200 μL ±0.6 ±1.2 ±0.4 ±0.8
2.5 mL
green 50 μL ±0.8 ±0.4 ±0.8 ±0.4
500 μL ±0.5 ±2.5 ±0.3 ±1.5
5 mL
blue 100 μL ±0.6 ±0.6 ±0.6 ±0.6
1 000 μL ±0.5 ±5.0 ±0.25 ±2.5
10 mL
orange 200 μL ±0.5 ±1.0 ±0.6 ±1.2
2 000 μL ±0.5 ±10 ±0.25 ±5.0
25 mL
red 500 μL ±0.4 ±2.0 ±0.6 ±3.0
5 000 μL ±0.3 ±15 ±0.25 ±12.5
50 mL
light grey 1 000 μL ±0.3 ±3.0 ±0.5 ±5.0
10 000 μL ±0.3 ±30 ±0.3 ±30
Liquid Water, double distilled, degased
Test temperature 20 to 25 °C, constant to ±0.5 °C
with original Eppendorf Combitips
Number of determinations 10, before dispensing, Combitip com-
pletely filled
Operating temperature +4 °C to +40 °C
Battery
Lithium button cell
3 V
210 mAh
Service life about 2 years
CAUTION!
CAUTION! Poor safety due to incorrect accessories
and spare parts.
The use of accessories and spare parts other than those
recommended by Eppendorf may impair the safety, func-
tion and precision of the device. Eppendorf cannot be held
liable or accept any liability for damage resulting from the
use of incorrect or non-recommended accessories and
spare parts or from the improper use of such equipment.
 Only use accessories and original spare parts
recommended by Eppendorf.
