9 Technical data
Concentrator plus / Vacufuge® plus — Operating manual
9 Technical data
9.1 Power supply
9.2 Ambient conditions
9.3 Weight / dimensions
9.4 Diaphragm vacuum pump for the complete system
Mains power connection Refer to ID plate 10 (see Fig. 1 or Fig. 2).
Power consumption: Refer to ID plate 10 (see Fig. 1 or Fig. 2).
(using largest external vacuum pump permitted)
Overvoltage category: II
Fuses: 4.0 AT (230 V)
6.25 AT (120 V/100 V)
Environment: For interior use only.
Ambient temperature: 15 to 35 °C
Max. relative humidity: 75 %, non-condensing humidity
Atmospheric pressure: Use at altitudes up to 6000 ft above MSL.
Degree of contamination: 2
5305 Basic device 5305 Complete system
Dimensions: Width: 320 mm (12.6 in.)
Depth: 369 mm (14.5 in.)
Height: 230 mm (9.1 in.) Width: 320 mm (12.6 in.)
Depth: 530 mm (20.9 in.)
Height: 298 mm (11.7 in.)
Weight excl. rotor: 17 kg (37.5 lbs.) 31 kg (68.3 lbs.)
Noise level: 50 dB(A) 50 dB(A)
Max. current: 1.4/1.6 A (230 V, 50/60 Hz)
3.0 A (120 V, 50 Hz)
3.6/3.8 A (100 V, 50/60 Hz)
Max. power: 180 W (230/120/100 V)
Motor protection: Thermal winding protection
Protection class to IEC 529: IP 54
Suction capacity (in accordance with DIN EN
60529; VDE 0470-1):
1.9/2.1 m 3 /h (50/60 Hz)
Achievable ultimate pressure (absolute): 9 mbar
Max. permissible pressure at the outlet
(absolute): 2 bar
Max. differential pressure between inlet and
outlet: 1 bar
Nominal speed at 50/60 Hz: 1,500/1,800 rpm
Radio interference protection class B
