16
Error codes
Accessories
• Water bath protective media:
AQ.1 Aquacide 1
• Tubing, hoses, adapters and couplings:
LT 5.20 Metal hose (isolated M16 x 1)
LT 5.21 PTFE hose (isolated M16 x 1)
H.PVC.8 PVC hose (nominal width 8)
H.PVC.12 PVC hose (nominal width 12)
H.SI.8 Silicone hose (nominal width 8)
H.SI.12 Silicone hose (nominal width 12)
See more accessories on www.ika.com.
Any malfunctions during operation will be identified by an error message on the display.
Proceed as follows in such cases:
F
Switch off device using the main switch at the back of the device
F Carry out corrective measures
F Restart device
Error code Effect Cause Solution
Err 02 Pump off
Refrigerating off Motor over current (rate current) - Reduce pump motor speed
- Use fluid with lower viscosity
- Check if the pump impeller is blocked
Err 04 Pump off
Refrigerating off Motor hall signal missing - Reduce pump motor speed
- Use fluid with lower viscosity
- Check if the pump impeller is blocked
Err 06 Pump off
Refrigerating off Too low liquid level - Check the fluid level and buoyage
Err 15 Pump off
Refrigerating off Compressor power supply
disconnected - Restart the device
Err 16 Pump off
Refrigerating off Suction temperature error - Restart the device
Err 17 Pump off
Refrigerating off Discharge temperature error - Restart the device
Err 19 Pump off
Refrigerating off Fluid temperature too high - Switch the device off and let the fluid cool down
Err 20 Pump off
Refrigerating off Condenser fan error - Restart the device
If the actions described fails to resolve the fault or another error code is displayed then take one of the following steps:
- Contact the service department
- Send the device for repair, including a short description of the fault.
• Tubing Insulations:
ISO. 8 Insulation (8 mm)
ISO.12 Insulation (12 mm)
• Additional accessories:
RV 10.5003 Pressure regulating valve
RV 10.5002 Filter
PC 1.1 Cable (RS 232)
USB cabel A - Micro B 2.0
Labworldsoft ®
