23
In accordance with IKA ® warranty conditions, the warranty pe-
riod is 24 months. For claims under the warranty please contact
your local dealer. You may also send the machine direct to our
factory, enclosing the delivery invoice and giving reasons for the
claim. You will be liable for freight costs.
Warranty
The warranty does not cover worn out parts, nor does it apply
to faults resulting from improper use, insufficient care or mainte-
nance not carried out in accordance with the instructions in this
operating manual.
Technical data
T 65 basic ULTRA-TURRAX ®
Motor data at 50 Hz at 60 Hz
Nominal voltage VAC 3 x 400 3 x 230 3 x 400 3 x 230
Rated voltage VAC 380 - 420 + 10% 220 - 240 + 10% 380 - 420 + 10% 220 - 240 + 10%
Rated frequency Hz 50 50 60 60
Connection Star connection Y Delta connection Δ Star connection Y Delta connection Δ
Motor speed rpm 2880 2850 3520 3520
Power consumption W 1800 1800 2200 2200
Power output W 1500 1500 1800 1800
Additional data
Speed rpm 7200 (± 300 rpm)
Perm. On- time % 100
Protection acc. DIN EN 60529 IP 54
Overvoltage category II
Protection class I
Contamination level 2
Protection on overload Overcurrent and undervoltage switch on
Perm. ambient temperature °C + 5 upto + 40
Perm. humidity % 80
Operating position On the stand, dispersion tool vertically
downwards
Volume available for processing (H
2
O) l 2 - 50
Drive Vane-cooled AC motor with Poly-V-belt
drive transmission stage
Stand mounting Flange in lower section of housing
Housing material Aluminium
Noise level (without disp. tool) dbA 75
Dimensions (WxHxD) mm 180 x 440 x 400
Weight kg 26
Operation at a terrestrial altitude m max. 2000 above sea level
Subject to technical changes!
