Aries Automotive 502504-2 User Manual
Installation instructions
Page 1 of 3
10/28/2009)
PARTS LIST:
Qty Description
Qty Description
1
Driver/Left Side Rail
2
10mm Lock Washer
1
Passenger/Right Side Rail
2
10mm Nuts
2
10mm x 30mm Bolt Plate
2
Plastic Retainer
2
10mm Flat Washer
INSTALLATION INSTRUCTIONS
502504/502504-2
08-2010 SMART CAR
Passenger
right Side
rail
Driver left
Side rail
10mm x 30mm Bolt Plate
(pictured with Plastic
Retainer installed for
example)
Fig 1A
Front of Vehicle
