Aries Automotive 364009-2 - Manual (Page 5)

2011 2500 Model Center Installation Pictured 2011 2500 Model Center Installation Pictured
Page 5 of 6 12/13/2010
Fig 10 Fig 10A
Place 10mm bolt
tab in hole.
10mm bolt tab
10mm Flat Washers
10mm Lock Washer
10mm Nut
10mm x 30mm Hex bolt,
10mm Hex nut
10mm Flat Washers
10mm Lock Washer
Fig 11
Fig 12
Passenger rear bracket
10mm x 30mm Hex bolt
10mm Hex nut
10mm Flat Washers
10mm Lock Washer
1/4" x 1 3/4” x 1 3/4"
square flat washer
Passenger rear
brace bracket
10mm x 30mm Hex bolt
10mm Hex nut
10mm Flat Washers
10mm Lock Washer
Driver rear
brace bracket
Factory skid shield bolt
re installed
Driver rear bracket
Fig 13 Fig 13A
Factory plastic plug
Driver side shown
Driver side shown
Place bolt tab into hole
