2011 2500 Model Front Installation Pictured 2011 2500 Model Center Installation Pictured
1500 Model Rear Installation Pictured 99-10 2500 Model Rear Installation Pictured
2011 2500 Model Rear Installation Pictured 2011 2500 Model Rear Installation Pictured
Page 4 of 5 05/10/2011
Fig 5 Fig 6
Fig 8
12mm x 30mm Hex bolt
12mm Hex nut
12mm Flat Washers
12mm Lock Washer
10mm x 30mm Hex bolt
10mm Flat Washers
10mm Lock Washer
10mm Hex nut
Fig 9
Push up
Fig 7 Fig 7A
Fig 10 Fig 10A
10mm x 30mm Hex bolt
10mm Flat Washers
10mm Lock Washer
10mm Hex nut 10mm x 30mm Hex bolt
10mm Flat Washers
10mm Lock Washer
Nut plate
Place 10mm bolt
tab in hole.
10mm bolt tab
10mm Flat Washers
10mm Lock Washer
10mm Nut
10mm x 30mm Hex bolt,
10mm Hex nut
10mm Flat Washers
10mm Lock Washer
10mm x 30mm Hex bolt,
10mm Hex nut
10mm Flat Washers
10mm Lock Washer 12mm x 30mm Hex bolt
12mm Hex nut
12mm Flat Washers
12mm Lock Washer 10mm x 30mm Hex bolt,
10mm Hex nut
10mm Flat Washers
10mm Lock Washer
