INSTALLATION STEPS
Page 2 of 2
Installation Diagram
STEP-1
STEP-2
STEP-3
STEP-4
STEP 1:Check the parts in the box carefully if match above list .
STEP 2:Pls prepare the tools for installation,follow as:10-12wrench,14-17 wrench .
STEP 3:Put the mount bracket into the girder of the car,and tighten it with
"T"Bolt
.
STEP 4:Install the Side Bar to the mount bracket,and tighten it with T"Bolt .
STEP 5:Installation is finished.
