Driver Side Installation Pictured
10mm x 30mm Hex Bolt
(2) 10mm Flat Washers
10mm Lock Washer
10mm Hex Nut
(Fig 8) 25-3500 Model Center Support
Bracket Installation Pictured.
NOTE: Support Bracket not required
on 2011 25-3500 Models
(Fig 7) 1500 Model Center Support Bracket
Installation Pictured
12mm x 30mm Hex Bolt
(2) 12mm Flat Washers
12mm Lock Washer
12mm Hex Nut
12mm x 30mm Hex Bolt
(2) 12mm Flat Washers
12mm Lock Washer
12mm Hex Nut
Front
Front
NOTE: Support Brackets not
required on 2011 25-3500 Models
