INSTALLATION INSTRUCTION
SIDE BAR PART #234075-2
03-06 GMC H2
Page 1 of 1
PART LIST
INSTALLATION STEPS
λ Read the instructions completely before you begin the installation. NOTE: Pictures are for
reference only, actual part may be different. Installation is the same.
λ You may need to periodically to re-tighten all hardware, such as one month or two month.
No. Name
Qty Remarks
○
1
Side bar
2
○
2
Hex bolt
16 M10×35
○
3
Flat washer 32 10mm
○
4
Lock nut
16 M10
1
. Begin installation by working on driver side of the vehicle (refer to Figures).
2. Line up holes of the driver-side Side Bar brackets to the back side of the vehicles rocker panel
protection brackets as shown in Figure, and secure to each bracket using (2) M10×35 bolts, (4)
10mm flat washers and (2) M10 lock nuts. Hand tighten.
3. Adjust Side Bar so that it is level and centered and tighten the two inner brackets first, and then
the two outer brackets to complete the driver-side assembly.
Repeat process for passenger side of vehicle to complete installation.
4. Test and make sure that the side bar is steadily fixed.
5. Installation is finished .
ATTENTION
Rocker panel protection
