Aries Automotive 202018-2 User Manual
Page 4
SIDEBAR
2013 TOYOTA RAV4
Page 3 of 4
4/25/13 Rev1(DP)
Driver Side Installation Pictured
Fig 5
(Fig 4A) 10mm T-Bolt
Fig 3B
Fig 3A
Front
10mm x 35mm Hex Bolt
(2) 10mm Flat Washers
10mm Lock Washer
10mm Hex Nut
Rear
Remove plug
(Fig 4B) Driver side front location pictured
Front
10mm x 40mm Carriage Bolt
10mm Rectangular Washer
10mm Plastic Retainer
(2) 10mm Flat Washers
(2) 10mm Lock Washers
(2) 10mm Hex Nuts
Fig 6
Front
