Page 4
—4—
OUTDOOR SOUND: OCTAVE BAND DATA - DECIBELS
dB — Sound Level (decibels)
PHYSICAL DATA
* Air filter pressure drop for non-standard filters must not exceed 0.08 in. wg.
ELECTRIC HEAT PRESSURE DROP TABLES
Small Cabinet: 024-036
Large Cabinet: 042-060
UNIT
602A
Frequency (Hz)
024
030
036
042
048
060
63
42.9
47.2
52.9
53.9
57.5
53.0
125
55.9
54.7
57.8
58.4
67.8
64.8
250
57.0
60.0
62.4
63.1
68.9
66.5
500
63.9
66.6
69.5
66.2
71.7
70.4
1000
66.8
67.0
72.3
66.8
72.7
73.2
2000
63.3
63.7
69.0
63.6
69.2
69.6
4000
59.0
59.5
65.4
59.9
65.7
67.1
8000
52.9
52.1
57.4
54.1
58.5
60.6
UNIT SIZE 602A
024
030
036
042
048
060
NOMINAL CAPACITY (ton)
2
2-1/2
3
3-1/2
4
5
OPERATING WEIGHT (lb)
299
320
328
350
355
428
COMPRESSORS
TYPE
Scroll
Quantity
1
REFRIGERANT*
REFRIGERANT METERING DEVICE
Accurater
Refrigerant (R-22) Quantity (lb.)
5.1
6.4
7.0
10.8
10.1
12.3
Orifice Indoor (in.)
0.065
0.073
0.076
0.080
0.088
0.093
Orifice Outdoor (in.)
OUTDOOR COIL
Rows—Fins/in.
Face Area (sq ft)
1—17
13.7
2—17
10.3
2—17
10.3
2—17
13.7
2—17
13.7
2—17
15.7
OUTDOOR FAN
Nominal (Cfm)
Diameter (in.)
Motor Hp (Rpm)
2350
22
1/8 (825)
2350
22
1/8 (825)
2800
22
1/4 (1100)
2800
22
1/8 (825)
3300
22
1/4 (1100)
3300
22
1/4 (1100)
INDOOR COIL
Rows—Fins/in.
Face Area (sq ft)
3—15
3.7
3—15
3.7
4—15
3.7
4—15
4.7
4—15
4.7
4—15
5.7
INDOOR BLOWER
Nominal Airflow (Cfm)
Size (in.)
Motor Hp (Rpm)
800
10 x 10
1/4 (1075)
1000
10 x 10
1/4 (1075)
1200
10 x 10
1/2 (1075)
1400
11 x 10
1/2 (1075)
1450
11 x 10
1/2 (1075)
1750
11 x 10
1.0 (1040)
RETURN-AIR FILTERS (In.)*
Throwaway
20 x 20 x 1
20 x 20 x 1
20 x 24 x 1
24 x 30 x 1
24 x 30 x 1
24 x 30 x 1
STATIC
CFM
500
600
700
800
900
1000
1100
1200
1300
1400
1500
1600
5 Kw
0.00
0.00
0.00
0.00
0.00
0.00
0.00
0.00
0.02
0.04
0.06
0.07
10 Kw
0.00
0.00
0.00
0.00
0.00
0.02
0.04
0.06
0.07
0.09
0.10
0.11
15 Kw
0.00
0.00
0.00
0.02
0.04
0.06
0.08
0.10
0.12
0.14
0.16
0.18
20 Kw
0.00
0.00
0.02
0.04
0.06
0.08
0.09
0.11
0.13
0.15
0.17
0.19
STATIC
CFM
1100
1200
1300
1400
1500
1600
1700
1800
1900
2000
2100
2200
2300
2400
2500
5 Kw
0.00
0.00
0.00
0.01
0.02
0.03
0.04
0.05
0.06
0.07
0.08
0.09
0.10
0.11
0.12
10 Kw
0.00
0.00
0.01
0.02
0.03
0.04
0.05
0.06
0.07
0.08
0.09
0.10
0.11
0.12
0.13
15 Kw
0.00
0.02
0.03
0.04
0.05
0.06
0.07
0.08
0.09
0.10
0.11
0.12
0.13
0.14
0.15
20 Kw
0.02
0.03
0.04
0.05
0.06
0.07
0.08
0.09
0.10
0.11
0.12
0.13
0.14
0.15
0.16
