3” SIDEBARS
08-14 TOYOTA HIGHLANDER (GAS & HYBRID)
Page 3 of 6 7/23/14 (DP)
(Fig 5) Driver/left front Bracket
Fig 4
Fig 6
Fig 2) Arrows indicate mounting holes
used for front Bracket installation
(Fig 3) 12mm Bolt Plate
Driver Side Installation Pictured
12mm Bolt Plate
6mm Nut Plate
Front
Remove rubber plug
Tie down loop
12mm Flat Washer
12mm Lock Washer
12mm Hex Nut
Front
Front
Front
