To protect your investment, wax this product after installing. Regular waxing is recommended to
add a protective layer over the finish. Do not use any type of polish or wax that may contain abrasives
that could damage the finish.
For stainless steel: Aluminum polish may be used to polish small scratches and scuffs on the finish.
Mild soap may be used also to clean the Sidebar.
For gloss black finishes: Mild soap may be used to clean the Sidebar.
Rive nut tool assembled
(Example shown with
rive nut installed)
(1) 8mm X 50mm hex
bolt
(1) 8mm thrush bearing
(1) 8mm end cap
(1) 8mm rive nut
Fig 4A
Fig 1 Fig 2
Location of
holes for C bolt
C Bolt placed in holes
Fig 3 Passenger front
bracket attached to
C Bolt
Attached with
(1) 8mm flat washer
(1) 8mm lock washer
(1) 8mm nut
(1) 25mm shim
(1) 8mm flat washer
Fig 4
Plastic push
pins to be
removed
