Aries Automotive 201009-2 - Manual (Page 5)

3" SIDEBAR
07-14 JEEP PATRIOT
Page 4 of 5 8/15/13 REV1 (DP)
Driver Side Installation Pictured
(2) 12mm Hex Bolts
(2) 12mm Lock Washers
(4) 12mm Flat Washers
(2) 12mm Hex Nuts
Fig 5B
Fig 4
(Fig 5A) Driver side front
Support Bracket pictured
(Fig 6A) 12mm Long Bolt Plate
Fig 6B
12mm Flat Washer
12mm Lock Washer
12mm Hex Nut
10mm Hex Bolt
(2) 10mm Flat Washers
10mm Lock Washer
10mm Hex Nut
Front
Front
Front
Rear
