Aries Automotive 207004-2 User Manual
Page 4
Page 4 of 4
9/22/10 (DP)
Passenger Side Installation Pictured
Complete installation
Sidebar to Rear Bracket
(2) 8mm x 25mm Hex Bolts
(2) 8mm Lock Washers
(2) 8mm Flat Washers
(2) 10mm x 30mm Large
OD Flat Washers
(2) 10mm Lock Washers
(2) 10mm Hex Nuts
(2) 10mm Hex Bolts
(2) 10mm Lock Washers
(4) 10mm x 20mm OD
STD Flat Washers
(2) 10mm Hex Nuts
Fig 7
Fig 8
1/2" x 2" Hex Bolt
1/2" Lock Washer
1/2" Flat Washer
Front
Fig 9
Rear
Rear
Fig 10
