FRONT PASSENGER SIDE
Page 3 of 3 4/8/2013)
Fig 2
Fig 1
Fig 3
Spacer tube
(1)12mm hex bolts
(1)12mm flat washer
(1)12mm lock washer
Fig 4
Front mount bracket
Attach to bottom of
frame rail snug
10mm square head
bolt.
(1)10mm hex bolts
(1)10mm flat washer
(1)10mm lock washer
Fig 5
(1)7/16-20 hex bolt
(1)7/16 flat washer
(1)7/16 lock washer
Passenger/right Side
Frame Bracket part A
10mm square head bolt
7/16-20Coupler nut
Rear brace bracket
7/16-20 hex bolt
7/16 flat washer
7/16 lock washer
Side bar
Front shown
Installation complete
