Aries Automotive 205033-2 User Manual
Page 3
PASSENGER SIDE INSTALLATION PICTURED
Page 3 of 3
Fig 3
Fig 5
Fig 6
Rear
(Fig 4) Rotate Bolt and Nut plate
to line up Nut with this hole in
body panel
12mm x 50mm Hex bolts
12mm x 38mm OD x 3mm Flat Washer
12mm Lock Washer
(1) 10mm x 35mm Hex Bolt
(1) 10mm Lock Washer
(1) 10mm Flat washer
(1) Bolt and Nut Plate
(2) 12mm Hex Nut
(2) 12mm Lock Washer
(2) 12mm Flat Washer
Fig 1A
Rear
Front
(1) Bolt and Nut Plate
(1) 12mm Hex Nut
(1) 12mm Lock Washer
(1) 12mm Flat Washer
(1) 10mm x 35mm Hex Bolt
(1) 10mm Lock Washer
(1) 10mm Flat washer
