INSTALLATION INSTRUCTIONS
SIDEBAR PART #204014-2/204014
92-99 CHEVY SUBURBAN
QTY DESCRIPTION
1
Side Bar, left side
1 Side Bar, right side
1 hardware kit
NOTE: Please read this information before installing. Check components received with components listed above. NO
DRILLING REQUIRED for installation of these side bars. To obtain correct installation, we recommend you to follow
these step by step installation instructions carefully. Please take care when installing this product to protect the finish and
your investment.
Step One: Check contents of the hardware.
QTY
DESCRIPTION
2
12mm x 1.75mm x 120mm hex bolts
6 1/2 flat washers
6 1/2 split lock washers
4 12mmx50mm hex bolts, GR.5
2 9/16 x 2 1/2 x 3/16 spacers, zinc plated
4 3” plastic rings
1 front support bracket, left side
1 front support bracket, right side
1 rear support bracket, left side
1 rear support bracket, right side
Step Two: Locate the side bar, one support bracket, one 3” plastic ring, two ½ x 2” hex bolts, two ½” flat washers and two ½”
split lock washers. Secure the bracket and ring to the side bar using the hardware listed in this step. (Fig #1) Do not fully
tighten hardware at his time. Repeat this procedure on the other end of the side bar using the support bracket.
Step Three: Locate one spacer, one 12mm hex bolt, two ½” flat washers and one ½” split lock washer. Remove the front cab
mount bolt located under the cab. Remove the rear spring hanger nut. “CAUTION” does not remove the rear spring
hanger bolt; doing so could result in injury or damage to the vehicle. Place the spacer over the spring hanger bolt and
position the rear support bracket over the rear spring hanger bolt. Secure the support bracket and spacer to the spring hanger
with the factory nut as shown in fig #2. Do not fully tighten the nut at this time. Position the front support bracket under the
front cab mount. Secure the support bracket to the bottom of the cab mount as shown in fig #3 using the remaining hardware
listed in this step. Fully tighten all hardware at this time.
