Passenger side shown – Aries Automotive 204039 User Manual
Page 3
Passenger Side Shown
Fig 1
Fig 2
Fig 3
Fig 2A
Passenger front
mount bracket
Front brace bracket
Rubber bushing
Passenger side rear leaf spring bolt
Rear leaf spring bolt
nut removed
Passenger
rear mount
bracket
View of inner spring
hanger
Fig 4
Fig 5
Secure with factory nut
Passenger
rear mount
bracket
Passenger rear
brace bracket
(1)12mm hex bolt
(2) 12mm flat washers
(1) 12mm lock washer
(1) 12mm hex nut
(1)12mm hex bolt
(1) 12mm flat washers
(1) 12mm lock washer
10mm hex bolt
10mm flat washers
10mm lock washer
10mm hex nut
