Aries Automotive B35-9003 User Manual
Page 2
Page 2 of 2
(Passenger Side Installation Shown)
Remove Factory
Tow Hooks Bolts
Replace factory bolts with the
included:
12-1.25 x 35mm Hex Bolts
12mm Lock Washers
12mm Flat Washers
12-1.75mm x 35mm Hex Bolts
12mm Lock Washers
12mm Hex Nuts
12mm Flat Washers
Cutout the driver
side tow hook cavity
Fig 1
Fig 2
Fig 3
Fig 4
Fig 5
Center plastic shroud
Bull bar attached w/o shroud for install view
