Aries Automotive 35-5TOW - Manual

PARTS LIST:
Qty Description Qty Description
2 Tow Hooks (Load Max10,000lbs) 8 10mm Hex Nuts
1 Driver/Left Mounting Bracket A 8 10mm Lock Washers
1 Driver/Left Mounting Bracket B 4 13mm x 65mm Hex Head Bolts
1 Passenger/Right Mounting Bracket A 8 13mm ID x 28mm OD x 3mm Flat Washers
1 Passenger/Right Mounting Bracket B 4 13mm Hex Nuts
8 10-1.5mm x 60mm Hex Head Bolts 4 13mm Lock Washers
16 10mm ID x 25mm OD x 2.5mm Flat Washers
Page 1 of 4
INSTALLATION INSTRUCTIONS
WORKS WITH BULL BARS B35-5006 / 35-5006
2010-12 RAM MEGA CAB 2010-12 RAM CREW CAB 2500 / 3500
PART# 35-5TOW
Passenger/right side
Mounting Bracket A
Driver/left side
Mounting Bracket A
Passenger/right side
Mounting Bracket B Driver/left side
Mounting Bracket B
Passenger/Driver
Tow Hooks
