Aries Automotive P2054-2 User Manual
Installation instructions
PARTS LIST:
1 Grille Guard
8 12mm lock washers
1 Driver/Left Mounting Bracket
2 10mm x 30mm Button Head Bolts
1 Passenger/Right Mounting Bracket
4 10mm x 27mm OD x 3mm Large Flat Washers
1 Driver/Left Top Bracket
4 10mm Hex Nuts
1 Passenger/Right Top Bracket
4 10mm lock washers
2 10mm x 30mm “T” Bolts
2 8mm Clip Nuts
2 12mm x 120mm Hex Bolts
2 8mm Flat washers
6 12mm x 35mm Hex Bolts
2 8mm Button head bolts
16 12mm x 32mm OD x 3mm Flat Washers
1 Support flange
8 12mm Hex Nut
Passenger/Right Side
Mounting Bracket
Driver/Left Side
Mounting Bracket
Passenger/Right
Side Top Bracket
Driver/Left Side
Top Bracket
(2) 10mm x 30mm T-Bolt Plates
(pictured with hardware)
INSTALLATION INSTRUCTIONS
2005-2013 TACOMA GRIL GUARD
PART# 2054 / 2054-2
(Skid Plate Must be removed- If Equipped)
(2) 8mm Nut Clips
Support Flange
Page 1 of 5 09/25/13
