Page 3 of 3 3/11/09 Rev 1(DP)
Driver Side Installation Pictured
6mm x 30mm Button
Head Bolts
6mm Flat Washers
6mm Lock Washers
12mm x 35mm Hex Bolts
12mm Flat Washers
12mm Lock Washers
12mm Hex Nuts
6mm x 30mm Button
Head Bolts
6mm Flat Washers
6mm Lock washers
Fig 5
Fig 6 Fig 7
Fig 8 Fig 9
Gently pull on the grille to
provide clearance for the Top
Bracket during installation
Driver/Left Side Short Top
Bracket Pictured
05-08 Xterra
Note position of notch for
grille clearance
Driver/Left Side Tall Top
Bracket Pictured
09 Xterra
Note position of notch
for grille clearance
Note: 09 Top Brackets are
slightly taller and longer with
notch on opposite side from
the 05-08 Brackets
05-08 Model
Pictured
05-08 Pictured
09 Xterra
06-08 Xterra 06-08 Xterra
09 Xterra
