Aries Automotive 9046-2 User Manual
Installation instructions
Page 1 of 4
9/11/08 (DL)
PARTS LIST:
1 Grille Guard
4 12mm Nylock Nuts
1 Passenger Side Mounting Bracket
4 12mm ID x 29mm OD x 3mm Flat Washers
1 Driver Side Mounting Bracket
8 12mm ID x 24mm OD Flat Washers
1 Passenger Side Top Bracket for Titan and 04-07 Armada
2 10-1.50mm x 25mm Hex Bolts
1 Driver Side Top Bracket for Titan and 04-07 Armada
2 10mm Nylock Nuts
1 Passenger Side Top Bracket for 08 Armada
4 10mm Flat Washers
1 Driver Side Top Bracket for 08 Armada
2 8mm x 35mm Hex Head Bolts
4 12-1.25mm x 45mm Hex Bolts GD 10.5
2 8mm Nylock Nuts
4 12-1.25mm x 30mm Hex Bolts
4 8mm Flat Washers
2 2” x 1 ¼” Adhesive Foam Strips
INSTALLATION INSTRUCTIONS
GRILL/BRUSH GUARD
04-08 NISSAN TITAN INCLUDES PRO 4-X / 04-08 ARMADA
PART NUMBER 9046/9046-2
Driver Side
Mounting Bracket
Passenger Side
Mounting Bracket
Driver Side Top
Bracket
08-On Armada
Passenger Side
Top Bracket
08-On Armada
Driver Side
Top Bracket
04-08 Titan /
04-07 Armadas
Passenger Side
Top Bracket
04-08 Titan /
04-07 Armadas
