Aries Automotive 4086 User Manual
Page 6
GRILLE GUARD
2015 SIERRA 25-3500
EXCLUDES DENALI MODELS
Page 5 of 6
7/9/14 (DP)
Passenger Side Installation Pictured
(Fig 13) Passenger side Top Inner
Bracket and “U” Rear Plate pictured
(Fig 11) Passenger side top Brackets pictured
Front
(Fig 10) Passenger side square tube support
between grille and radiator pictured
(Fig 9) Remove plastic cover on top of grille
Front
(Fig 12) Passenger side “U” Rear Plate pictured
Front
(2) 6mm x 25mm Hex Bolts
(2) 6mm Lock Washers
(2) 6mm Flat Washers
“U”-Rear Plate
Top Inner Bracket
Outer Top
Bracket
Remove hardware securing grille to vehicle.
Carefully pull the grille straight out from the
vehicle. Tilt the top of the grille forward only
to access the area behind the grille
Front
