Driver side installation shown) – Aries Automotive 3060-2 User Manual
Page 2
Page 2 of 2
2/15/07 (AM)
10mm x 25mm Hex Head Bolts,
10mm Flat Washers
(Driver Side Installation Shown)
10mm x 30mm Hex
Head Bolts,
10mm Lock Washers,
10mm Flat Washers
Existing Bolts
and Nuts
Top Support
Bracket
10mm 25mm Button
Head Bolt,
10mm Flat Washers,
10mm Nylock Nut
12mm 30mm Hex
Head Bolt,
12mm Flat Washers,
12mm Nylock Nut
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Installation Complete
Insert this bolt first
