7.2
7-4 A38E Work Platform
Illustrated Parts Breakdown
CHASSIS ASSEMBLY A38E -
500202-000
ITEM PART NO. DESCRIPTION QTY.
1 500210-000 A38E CHASSIS WELDMENT 1
2 500232-000 A38E DRIVE MOTOR COVER 1
3 500233-000 A38E CHASSIS BODY COVER 1
4 500231-000 A38E MODULE COVER 2
5 500052-000 GRAB HANDLE 6
6 057727-000 TWIST SCREW FASTENER 4
7 500259-000 A38E COVER GRIP LATCH 4
8 500261-000 A38E MANIFOLD BLOCK 1
9 500260-000 A38E HYDRAULIC RESERVOIR ASSY. 1
10 057532-000 RESERVOIR RETURN LINE FILTER 1
11 058074-000 FILTER ELEMENT ASSEMBLY 1
12 058834-000 DRIVE MOTOR, LEFT HAND SIDE 1
13 057569-001 TACHOMETER ADAPTOR KIT 1
14 057569-000 TACHOMETER 1
* 057570-000 TACHO COUPLING 1
15 505566-000 DRIVE MOTOR, RIGHT HAND SIDE 1
16 057281-000 TILT SENSOR 1
17 057530-000 MOTOR/PUMP ASSEMBLY 1
18 057578-000 REAR WHEEL NUT - M14 10
19 057668-001 REAR WHEEL TYRE & RIM ASSY. 2
20 057667-003 FRONT WHEEL TYRE & RIM ASSY. 2
21 057666-000 FRONT WHEEL NUT - M16 10
22 057669-000 STEERING STUB AXLE ASSY. 2
23 058427-000 A38E TORQUE ARMS 2
24 500253-001 A38E STEERING LINKAGE PIN 4
* 500252-000 CIRCLIP 16 mm 4
* 500408-000 BUSHINGS 2
25 500250-000 A38E STEERING LINK ARM 2
26 058463-000 A38E STEERING CYLINDER 1
* 058494-035 MOUNTING BOLTS M12 4
* 056021-012 SPRING WASHER 4
27 0260021 CHARGER 240/100VAC 50/60Hz 1
28 057586-000 HORN 1
29 500234-002 A38E CHASSIS SIDE DROP PANEL 1
- WITH SLOTS
30 501074-000 BATTERY 6V 220AH 8
* 010154-000 TERMINAL COVERS 18
31 - - -
32 501862-000 MOTOR CONTROLLER ASSEMBLY 1
33 500234-001 A38E CHASSIS SIDE DROP PANEL 1
- WITHOUT SLOTS
34 057580-000 DRIVE GEARBOX 1
