Section
7.2
7-2 A38E Work Platform
Illustrated Parts Breakdown
FINAL ASSEMBLY A38E -
500200-001 (ANSI Version)
500200-000 (CE Version)
ITEM PART NO. DESCRIPTION QTY.
- 500202-000 Chassis Assembly -
- 500201-000 Booms and Posts Assembly -
- 057603-000 Cage and Cradle Assembly -
- 057580-000 Drive Reduction Gearbox Assembly -
- 057568-000 Traction Motor Assembly - Right Hand -
058834-000 Traction Motor Assembly - Left Hand -
- 057530-000 Motor / Pump Assembly -
- 057667-003 Front Wheel Assembly -
- 500284-001 Pinion Gearbox & Slew Bearing Assy. -
- 500261-000 Manifold Block Assembly -
- 504504-000 Lower Lift Cylinder Assembly -
- 504505-000 Upper Lift Cylinder Assembly -
- 058461-000 Telescopic Cylinder Assembly -
- 058463-000 Steering Cylinder Assembly -
- 058734-000 Master Cylinder Assembly -
058735-000 Slave Cylinder Assembly -
- 500483-000 Pump Motor Control Unit Assembly -
- 500490-000 Lower Control Box Assembly -
- 500491-000 Upper Control Box Assembly -
- 500482-000 Circuit Board Box & Harnesses -
- - Cables & Electrical Components -
- 500360-000 Hose Assembly -
- - Decal Kit -
Rear Wheel Assembly 057667-001
