Introduction
114110-000 X-Series - Operator Manual Page 3
I NTRODUCTION
This manual covers the X-Series Aerial Work Platform. This manual must be stored on the machine at
all times.
Read, understand and follow all safety rules and operating instructions before attempting to operate the
machine.
G ENERAL D ESCRIPTION
Figure 1: X 26 Ultra Narrow
W A R N I N G ! !
DO NOT use the machine if all
guardrails are not properly in place and
secured.
1. Platform Controls
2. Manual Case
3. Platform Extension
4. Platform
5. Elevating Assembly
6. Chassis
7. Power Module
8. Control Module
9. Chassis Controls
10. Batteries
11. Battery Charger
12. Charger Outlet Plug
13. Hydraulic Fluid Reservoir
14. Emergency Lowering Valve Knob
X20N & X26UN
X20W & X26N
X31N
4
5
6
7
7
7
3
3
3
9
8
8
8
8
9
14
12
7
9
2
1
1
4
5
6
2
1
4
10
13
11
5
6
2
