Page 18 114110-000 X-Series - Operator Manual
Labels
L ABELS
These labels shall be present and in good condition before operating the machine. Be sure to read, under-
stand and follow these labels when operating the machine.
23) 005221-000
21) 066552-000
1) 101251-000
7) 101250-000 – X26UN
7) 101250-003 –X20W
7) 101250-004 – X26N
7) 101250-005 – X31N
7) 101250-002 – X20N
8) 014222-003-99
9) 066553-000
26) 066555-000
6) 060197-000
10) 061205-005
15) 061220-002
2) 066550-000
17) 066554-000
3) 066561-000
3) 066561-002 – X31N
12) 066558-000
12) 066558-002
X31N
20) 010076-001
16) 066556-000
5) 066559-000
22) 062562-001
X20N–X20W–X26N
22) 062562-001
X26UN–X31N
4) 101222-005
11) 061787-001 18) 066561-003
24) 066522-000
25) 066556-001
19) 107051-000
13) 101252-005
X20N–X26N&UN
13) 101252-006
X31N
13) 101252-004
X20W
14) 068639-000
TIP-OVER HAZARD
DANGER
BATTERIES ACT AS COUNTERWEIGHT
66 LBS OR MORE
EACH REPLACEMENT BATTERY SHALL WEIGH
BATTERY
MAINTAIN BATTERY FLUID
AT RECOMMENDED LEVEL
Explosive gas is
generated when
charging batteries.
Do not expose to
sparks or flames.
WARNING
DANGER
TIP-OVER HAZARD
MAXIMUM DISTRIBUTED LOAD
250 LBS. OR 1 OCCUPANT
ON EXTENDED DECK
MAXIMUM SIDE LOAD 100 LBS.
MAXIMUM DISTRIBUTED
PLATFORM LOAD 500 LBS.
OR 2 OCCUPANTS
MAXIMUM SIDE LOAD 100 LBS.
WARNING
MAXIMUM DISTRIBUTED
PLATFORM LOAD 750 LBS.
OR 2 OCCUPANTS
MAXIMUM SIDE LOAD 113 LBS.
WARNING
MAXIMUM DISTRIBUTED
PLATFORM LOAD 1000 LBS.
OR 4 OCCUPANTS
MAXIMUM SIDE LOAD 200 LBS.
WARNING
101250-003
MAXIMUM DISTRIBUTED
PLATFORM LOAD 1000 LBS.
OR 3 OCCUPANTS
MAXIMUM SIDE LOAD 150 LBS.
WARNING
101250-004
MAXIMUM DISTRIBUTED
PLATFORM LOAD 700 LBS.
OR 3 OCCUPANTS
MAXIMUM SIDE LOAD 150 LBS.
WARNING
101250-005
FORK-LIFT HERE
FOR TRANSPORTING ONLY
014222-003-99
WARNING
KEEP CLEAR OF
SCISSORS
BLOCK SCISSORS
BEFORE
SERVICING
TIP-OVER HAZARD
DANGER
Failure to read, understand and obey the following safety rules
will cause death or serious injury
DO NOT elevate or drive elevated on
slopes or soft ground
DO NOT drive into holes or over
drop offs
No more than one person or 250 Lbs. on
slide out platform
ELECTROCUTION HAZARD
DO NOT operate within ten feet of power
lines. THIS MACHINE IS NOT INSULATED.
Look up, down and around for electrical
wires
FALL HAZARD
DO NOT climb on guardrail
Lower top rail and secure gate or chain
across entrance
DO NOT use ladders or scaffolding on platform
Make sure guardrails are fastened securely
DO NOT climb down scissors.
SCISSOR BRACE INSTRUCTIONS
POSITIONING STORAGE
STORED
INSTALLED
USING LOWER CONTROLS, RAISE
PLATFORM TO APPROXIMATELY
8 FT. 1.
ROTATE SCISSOR BRACE UP AND
OVER UNTIL IT HANGS STRAIGHT
DOWN. 2.
LOWER PLATFORM UNTIL BRACE
YOKE ENGAGES LOWER SCISSOR
TUBE. 3.
USING LOWER CONTROLS, RAISE
PLATFORM UNTIL SCISSOR BRACE
CLEARS. 1.
ROTATE RACE UP AND OVER
UNTIL IT RESTS ON CYLINDER
MOUNT TUBE. 2.
TIP-OVER HAZARD
DANGER
BATTERIES ACT AS COUNTERWEIGHT
60 LBS OR MORE
EACH REPLACEMENT BATTERY SHALL WEIGH
CHARGER
BATTERY
BATTERY DISCONNECT
LOCATED INSIDE
USE DISCONNECT BEFORE
SERVICING WORK PLATFORM
OR BATTERIES
MAXIMUM
WHEEL LOAD
1750 LBS.
MAXIMUM
WHEEL LOAD
1600 LBS.
101252-004
MAXIMUM
WHEEL LOAD
1850 LBS.
101252-006
FORWARD
UP
NEUTRAL
DOWN
REVERSE
EMERGENCY
STOP
DRIVE
LOW
LIFT HI
