Controls and Indicators
068017-021 UL25, UL32 & UL40
Operation Manual
Page 5
C
ONTROLS AND
I
NDICATORS
Figure 2:
Controls and Indicators
1
1 Emergency Stop Switch
2. Power On Button
3. Up Button
4. Down Button
5. Battery Charger
1 LED ( Indicates that
optional Emergency
Down from the platform
battery needs replac-
ing).
2. Emergency Stop
Switch
3. Key Switch
4. Emergency Lowering
Valve
5. Orbit Level
6. Outrigger Indicator
Lights
3
4
1
2
Platform Controls
Chassis Controls
2
3
4
5
6
