Page 6 TM12 Work Platform
Figure 6: Transporting the Work Platform
B Y F ORKLIFT
Forklift from the side by lifting under the chassis modules.
B Y C RANE
Secure straps to chassis lifting/tie down points only.
B
Y
T
RUCK
1. Maneuver the work platform into transport position and chock wheels.
2. Secure the work platform to the transport vehicle with chains or straps of adequate load
capacity to the chassis lifting/tie down points.
3. Open the Emergency Lowering Valve. The platform must be in the fully lowered position for
transport.
T RANSPORTING W ORK P LATFORM
Fo
rklift:
Side
Lift/Tie Do
wn Points
D A N G E R ! !
Forklifting is for transporting only.
See specifications for weight of work platform and be certain that forklift is of
adequate capacity to lift the work platform.
C A U T I O N ! !
Overtightening of chains or straps attached to tie down lugs may result in
damage to work platform.
