S PECIFICATIONS *
*Specifications are subject to change without notice. Hot weather or heavy use may affect performance.
Refer to the Service Manual for complete parts and service information.
The TM12 meets or exceeds all applicable requirements of OSHA and ANSI A92.6-1999
ITEM SPECIFICATION
Platform Size 29 in. x 41 in. (73,7 cm x 1,04 m) Inside Toeboards
Maximum Platform Capacity 500 lbs. (227 kg)
Maximum Number of Occupants Two people
Height
Working Height 18 ft. (5,5 m)
Maximum Platform Height 12 ft. (3,66 m)
Minimum Platform Height 19 in. (48,3 cm)
Dimensions
Weight 1710 lbs. (776 kg)
Overall Width 30 in. (76 cm)
Overall Height 65 in. (165 cm)
Overall Length 53.5 in. (1,36 m)
Driveable Height 12 ft. (3,66 m)
Drive Speed
Platform Lowered 2.27 mph (3,65 km/h)
Platform Raised .62 mph (0,99 km/h)
Energy Source 24V battery pack
Four 220 ampere hour, 6 Volt batteries, min. wt. 62 lbs. (28,12 kg) each
4 HP DC electric motor
System Voltage 24 VDC
Battery Charger 20 AMP, 110/220 VAC
Hydraulic Tank Capacity 1.9 gal (7,2 L)
Maximum Hydraulic System
Pressure
3000 psi (207 bar)
Hydraulic Fluid
Above 32° F [0° C]
Below 32° F [0° C]
Below 0° F [-17° C] ISO #46
ISO #32
ISO #15
Lift System One Single Stage Lift Cylinder
Drive Control Proportional
Control System Proportional Control Handle with Interlock, Selector Switch,
Red Mushroom Emergency Stop Switches
Drive System Dual Front Wheel Hydraulic Motors
Tires 12 in. (30,5 cm) diameter solid rubber, Non-marking
Parking Brakes Dual, Spring Applied, Hydraulic Release
Turning Radius 14.5 in. (37 cm) Inside
Maximum Gradeability 25% (14º)
Wheel Base 38.5 in. (97,8 cm)
Guardrails 45 in. (1,14 m)
Toeboard 6 in. (152 mm)
