Operation
16 T40RT/T46JRT – 1430001
Driving and Steering
Danger
The aerial platform can tip over if it becomes unstable.
Death or serious injury will result from a tip-over ac-
cident. Do not drive an elevated aerial platform on
soft, uneven, or sloping surfaces. Do not drive the
machine on grades that exceed the percent grade-
ability of that particular machine.
For operation of T40RT machines on grades up to 45
percent, it is recommended that the main boom be near
horizontal to provide adequate ground clearance.
A 45 percent grade is a 1.4 m (54″) vertical rise in
3.05 m (10′) horizontal length.
For operation of T46JRT machines on grades up to 40
percent, it is recommended that the main boom be near
horizontal and the jib be elevated just enough to provide
adequate ground clearance.
A 40 percent grade is a 1.2 m (48″) vertical rise in
3.05 m (10′) horizontal length.
Avoid driving with the platform over the front end of the
chassis. In this position the machine is difficult to control
because:
Drive and steer control movements and their resulting
machine movements are reversed.
When driving fast, sudden turns or stops produce
more severe reactions to platform occupants.
More turning space is required to prevent the platform
from colliding with obstacles several feet beyond the
path of the tires.
Warning
Death or serious injury could result from improperly
driving or steering the aerial platform. Read and un-
derstand the information in this manual and on the
placards and decals on the machine before operating
the aerial platform on the job.
The blue and yellow arrows on the chassis indicate the
direction the chassis will move when the drive or steer
control is moved toward the corresponding color.
When the machine is in the stowed position, with the
booms centered between the rear wheels, the direction
of drive and steer control movement corresponds with
the direction of chassis movement.
When the turntable is rotated from the stowed position,
with the booms to either side of or in front of the chassis,
the direction of control movement does not correspond
with the direction of chassis movement.
•
•
•
To avoid confusion, always drive to the work area
or move between work areas with the turntable and
booms in the stowed position.
After arriving at the work area, the booms may be
positioned to the side or the front of the chassis for
final positioning.
Always look in the direction of movement as indicated
by the directional arrows on the chassis.
Use the following procedure to operate the drive and
steer functions.
1. Determine the desired drive range for the specific driv-
ing conditions. Place the switch in the appropriate posi-
tion to achieve the desired drive wheel operation.
Use high range (rabbit) when traveling across firm,
flat, level surfaces. High range can only be activated
when the booms are stowed. High range is for high
speed, low torque operation.
Use low range (turtle) for driving on loading ramps or
other steep grades and when safety considerations
demand slow deliberate machine movement. Low
range is for low speed, high torque operation.
2. Place the drive/boom selector switch in the drive
position.
3. Step down on the platform foot switch.
4. Push the drive joystick forward to move the chas-
sis forward, the direction of the blue arrow. Pull the
joystick backward to move the chassis backward,
the direction of the yellow arrow. The drive speed is
proportional to the joystick position.
5. To stop drive motion, return the joystick to neutral.
6. The steer switch is a momentary contact, rocker
switch on top of the drive joystick. This switch controls
the two front wheels to steer the aerial platform.
To steer to the right, hold down the right side of the
steer switch.
To steer to the left, hold down the left side of the
steer switch.
Note
The steering wheels are not self-centering. Set the steer-
ing wheels straight ahead after completing a turn.
7. After driving to the desired location, release the foot
switch, or push the emergency stop button to apply
the parking brakes.
•
•
•
•
•
•
•
