Chapter 4 – Safety Devices
16
SB85J Fixed Axle – 0112975
Driving Lights
Optional headlights and blinking tail lights may be in-
stalled on the machine. The headlights are located on
the top of the front cowling. The tail lights are mounted on
the sides of the rear cowling (refer to Figure 4.10).
Figure 4.10 – Tail Light
Driving lights help improve visibility while driving the aerial
platform and help others see it too. Driving lights are not
for driving on public roadways.
Platform Work Lights
Optional platform work lights may be located on the top
rail of the platform (refer to Figure 4.11), one on each side
of the upper control panel.
Figure 4.11 – Platform Work Lights
Use the platform lights to improve visibility while working
aloft in dimly lit areas. Do not use the platform work lights
to drive on public roadways.
Figure 4.8 – Right Side of Upper Control Panel
Drive Motion Alarm
An optional drive motion alarm may be provided on the
machine. When the drive/steer control is moved out of
neutral the alarm sounds, in short beeps, to warn per-
sonnel in the work area to stand clear.
Flashing Light
An optional red or amber flashing light may be located on
the top of the boom near the base end (refer to Figure
4.9). The flashing light warns personnel that the aerial
platform is in the area.
Figure 4.9 – Flashing Light
The light flashes at about one flash per second when the
engine is running.
Tail Light
Horn Button
Flashing Light
