21 S1930E/S1932E/S2632E – 1360417
Specifications
General Specifications – S1932E
Aerial Platform
Working height 7.6 m (25′)
Maximum platform height 5.8 m (19′)
Turning radius
Inside 12.7 cm (5″)
Outside 1.64 m (64.5″)
Wheelbase 1.37 m (4′ 6″)
Ground clearance
Pothole protector raised 6.3 cm (2.5″)
Pothole protector lowered 1.9 cm (0.75″)
Maximum wheel load 642 kg (1,416 lbs)
Maximum ground pressure 12.3 kg/cm² (175 psi)
Weight, EVW
Approximate 1,361 kg (3,000 lbs)
Stowed width 81.3 cm (32″)
Stowed length 1.9 m (6′ 2″)
With step removed 1.7 m (5′ 6″)
Stowed height 2.17 m (6′ 7″)
Rails up 216.5 cm (85.25″)
Rails down 164 cm (64.5″)
Platform
Dimensions
Main 74 cm x 156 cm (29″ x 61.5″)
Extension 61 cm x 91.4 cm (24″ x 36″)
Total length with extension 247.5 cm (97.5″)
Guardrail height
Rails up 111.8 cm (44″)
Rails down 62.2 cm (24.5″)
Toeboard height 15.2 cm (6″)
Rated work load
Total 227 kg (500 lb)
Extension 113.3 kg (250 lb)
Maximum number of occupants 1 outdoors
2 indoors
Function Speed
Platform raise 12 to 20 seconds
Platform lower 20 to 26 seconds
High Drive
Platform lower than 1.8 m (6 feet)
0 to 3.2 km/h (0 to 2 mph)
Low Drive
Platform higher than 1.8 m (6 feet)
0 to 0.6 km/h (0 to 0.4 mph)
Drive System
Standard Two-wheel drive
Gradeability 25%
Maximum drive height 5.8 m (19′)
Drive/Lift Level Sensor Interlock
Side-to-side 2 degrees
Front-to-rear 4 degrees
Tires
Nonmarking solid rubber 30.5 cm x 10.2 cm (12″ x 4″)
Electrical System
Voltage 24 V DC negative chassis ground
Source Four - 6 V 220 amp hour batteries
Fluid recommended distilled water
Charger 25 amp
Hydraulic System
Maximum pressure 20,684 kPa (3,000 psi)
Reservoir capacity 11.35 l (3 US gal)
System capacity 13.2 l (3.5 US gal)
Maximum operating temperature 71°C (160°F)
Hydraulic fluid recommended
Above -13°C (10°F) ISO VG32 (Mobil DTE-13M)
Below -13°C (10°F) ISO VG15 (Mobil DTE-11M)
Ambient Air Temperature Operating Range
Celsius -18°C to 43°C
Fahrenheit 0°F to 110°F
Maximum Wind Speed
Gust or steady 12.5 m/s (28 mph)
Vibration less than 2.5 m/sec²
Sound Pressure Level At work station below 70 dB(A)
