Controls and Indicators
PUSH6/PUSH8/PUSH10 – 0120843 7
Ground Operation Button
The ground operation button prevents platform movement
if the platform raise or lower button is accidentally pressed.
This switch is spring returned to the off position.
Press and hold the ground operation switch inward con-
tinually to operate the machine from the lower controls.
Platform Raise/Lower Buttons
The platform raise/lower buttons are used to raise or
lower the platform. The buttons are spring returned to
the off position.
Press and hold the platform raise button to raise the
platform.
Press and hold the platform lower button to lower the
platform.
An alarm will sound as the platform lowers.
Battery Charger Mode Selector
The battery charger may be operated on either 110V or
230V/240V electrical circuits.
Move the toggle switch to the left for operation on
110V circuits.
Move the toggle switch to the right for operation on
230V/240V circuits.
In the middle position, the battery charger is off and
will not charge.
Upper Controls
The upper controls (refer to Figure 3) are located on the
control panel at the front of the platform.
The following controls are located on the upper control
panel:
Interlock button
Battery condition indicator
Platform raise/lower buttons
Emergency stop button
Warning
The aerial platform is free to move when the brakes
are released. Death or serious injury can result.
Engage the brakes before operating the aerial plat-
form.
•
•
•
•
•
•
•
•
•
•
Emergency Stop Button
The emergency stop is a two-position, red push button
on the right side of the upper control panel.
Push the button inward to disconnect power from all
control circuits at the upper controls.
Twist the button clockwise to restore power.
Push the button in when the upper controls are not in use
to help protect against unintentional platform operation.
Interlock Button
The interlock button prevents platform movement if the
platform raise or lower button is accidentally pressed. This
switch is spring returned to the off position.
Press and hold the interlock button inward continually to
operate the machine from the upper controls.
Platform Raise/Lower Buttons
The platform raise/lower buttons are used to raise or
lower the platform. The buttons are spring returned to
the off position.
Press and hold the platform raise button to raise the
platform.
Press and hold the platform lower button to lower the
platform.
An alarm will sound as the platform lowers.
•
•
•
•
•
