PAM SERIES DECAL INSPECTION(SINGLE)
Part No.
Description
QTY.
9121015
Control panel on work platform
1
9121017
AC Control panel
1
9121011
DC control panel
1
9221013
Machinery label
1
9321013
Leveling and justment(lift)
2
9321015
Leveling and justment(right)
2
9323011
Brief operating instruction
1
9323013
Gate of platform
1
9323015
Label--Down
1
9323017
Label--Stop
1
9323019
Label—Up
1
9341011
Label—Back-up
1
9421021
Warning—Make sure to position the stabilizers before operating
4
9421023
Max. Load on each stabilizer—2800N
4
9422011
Capacity:125kg
1
9422021
Warning—Make sure the chock is in place during maintenance
1
9422023
Warning—shearing danger, keep hands away
1
9423011
Notice—Allowed number of persons: ONE
1
9423023
Max. Allowed Manual force—200N
1
9423025
Max. Allowed wind speed—10.7m/s
1
9423027
Warning—Keeping safe clearance with live electric conductors
1
9423029
Caution— The masts or the platform must not bump into any barrier or moving object
during lifting
1
9423031
Warning—Ensure all atabilizers are engaged properly before elevating the platform
1
9423033
Warning— The manual forces applied by persons on the work platform should not
exceed the permltted limit when it is raised
1
9423035
Danger—Any unsafe operation pattern on the platform is strictly forbidden
1
9423037
Danger—Don′t move the whole equipment when in the course of lifting and lifted
1
9423039
Danger— The addition of any device, such as ladder, to increase the working height is
strictly not allowed.
1
9423041
Danger-- Don′t park at the slope, pay attention to the obstacle when moving at the
slope.
1
9441011
CE label
1
9441021
Danger—Please don′t stand
1
9421019
Caution—Electrocution hazard
1
9443017
Notice—The charging socket of the battery (For DC)
1
9443019
Notice—Recharging lasts at least 12 hours (For DC)
1
Decal Inspection:
Use the pictures on the next page to verify that all decals are legible and in place.
Below is a numerical list with quantities and descriptions.
