2. Operation & Specifications
2 - 10
1. Ensure that the Key Switch on the Lower Control Box is turned to the Platform Controls
position and both emergency stop buttons are off (twist clockwise if necessary).
2. Check the Display B.C.I. is illuminated. If not, the battery may need recharging.
3. Enter the Platform through the entrance at the rear of the MB20/26J and ensure that the
drop bar is in position. Raise and lock the entry step.
4. Before using the machine all local Safety Regulations involving helmets and restraining
devices should be observed. Safety harness lanyards, not exceeding 1 metre in length,
should be attached to anchor points in cage floor.
5. Check if the audible alarm sounds due to un-level ground. None of the functions can
work if the machine is not level.
TRAVEL WITH WORK PLATFORM LOWERED
Refer to Tables 1 & 2 for controls and indicators.
1. Verify that both Lower and Upper Control Console Emergency Stop Button is in the ‘ON’
position (turn clockwise to reset).
2. Turn the key switch on the lower control panel to the platform controls position.
3. Climb into the Platform and select drive using the drive / lift selector toggle switch.
Ensure that the drop bar is in position.
4. Check that the route is clear of persons, obstructions, pot holes or ledges and is capable
of supporting the wheel loads. Also, check that the clearances above, below, and to the
side of the Work Platform are sufficient.
5. To steer the MB20/26J, activate the Deadman Switch while pushing the Steering
Thumb-switch, on top of the Joystick, LEFT or RIGHT to turn the wheels. Observe the
tyres while manoeuvring to ensure correct direction.
NOTE: Steering is not self-centring. The wheels must be returned to the straight ahead
position by operating the Steering Switch.
TRAVEL WITH WORK PLATFORM ELEVATED
Refer to Tables 1 & 2 for controls and indicators.
NOTE: The Work Platform will travel at reduced speed when in the elevated position.
1. Check that the route is clear of persons, obstructions, pot holes or ledges and is capable
of supporting the wheel loads. Also, check that the clearances above, below and to the
side of the Work Platform are sufficient.
2. Ensure that the pothole guards remain in the extended (down) position during elevated
travel.
!
!
If the machine stops driving and the Tilt Alarm sounds, lower the
Platform
immediately.
Using the Emergency Override functions, move the machine to a
level location before re-elevating the platform.
Travel with platform elevated
ONLY on firm and level surfaces.
C A U T I O N
