12
*
*Specifications subject to change without notice. Refer to the Service Manual for complete parts and service information. Hot weather
or heavy use may reduce performance. Meets or exceeds all applicable requirements of OSHA and ANSI A92.6-1999
ITEM LX31 LX41 LX50
Platform Size (Inside toeboards)
Standard 143.38 in x 70 in. [3,64 m x 1,78 m] 143.38 in. x 70 in. [3,64 m x 1,78 m] 143.38 in. x 70 in. [3,64 m x 1,78 m]
Slide Out Deck Extended 179.38 in. x 68 in. [4,56 m x 1,73] 179.38 in. x 68 in. [4,56 in. x 1,73 m] 179.38 in. x 68 in. [4,56 m x 1,73 m]
Max. Platform Capacity
Standard 2,000 lbs. [907 kg] 1,500 lbs. [680 kg] 1,000 lbs. [454 kg]
w/ Extension 2,000 lbs. [907 kg] 1,500 lbs. [680 kg] 1,000 lbs. [454 kg]
on Extension 500 lbs. [227 kg] 500 lbs. [227 kg] 500 lbs. [227 kg]
Max. No. of occupants
Standard 8 people 6 people 4
on Extension 2 people 2 people 2
Height
Working Height 37 ft. [11,4 m] 47 ft. [14,33 m] 56 ft. [17 m]
Max. Platform Height 31 ft. [9,45 m] 40 ft. 6 in. [12,34 m] 49 ft. 6 in. [15,09 m]
Min. Platform Height 56.25 in. [1,43 m] 65.25 in. [1,66 m] 76 in. [1,93]
Drivable Height 31 ft. (9,4 m) 40 ft. 6 in. (12,3 m) 49 ft. 6 in. [12,34]
Dimensions
Weight, Standard 2WD: 9,400 lbs. [4,264 kg]
4WD: 9,630 lbs. [4,368 kg] 2WD: 10,560 lbs. [4,790 kg]
4WD: 10,920 lbs. [4,953 kg] 2WD: 12,120 lbs. [5,498 kg]
4WD: 12,480 lbs. [5,661 kg]
Weight, w/extension 2WD: 9,830 lbs. [4,459 kg]
4WD: 10,060 lbs. [4,563 kg]
2WD: 10,990 lbs. [4,985 kg]
4WD: 11,350 lbs. [5,148 kg] 2WD: 12,550 lbs. [5,693 kg]
4WD: 12,910 lbs. [5,856 kg]
Overall Width 90 in. [2,29 m] 90 in. [2,29 m] 90 in. [2,29 m]
Overall Height 99.75 in. [2,53 m] 108.75 in. [2,76 m] 108.75 in. [2,76 m]
Overall Length, Standard 160 in. [4,06 m] 160 in. [4,06 m] 160 in. [4,06 m]
Surface Speed
Platform Lowered 0 to 3.1 mph [0 to 5,0 km/h] 0 to 3.1 mph [0 to 5,0 km/h] 0 to 3.1 mph [0 to 5,0 km/h]
Platform Raised 0 to 0.3 mph [0 to 0,48 km/h] 0 to 0.3 mph [0 to 0,48 km/h] 0 to 0.3 mph [0 to 0,48 km/h]
System Voltage 12 Volt DC 12 Volt DC 12 Volt DC
Hydraulic Tank Capacity 28.3 US Gallons [107,13 l] 28.3 US Gallons [107,13 l] 28.3 US Gallons [107,13 l]
Maximum Hydraulic System Pressure 3000 psi [206,8 bar] 3000 psi [206,8 bar] 3000 psi [206.8 bar]
Hydraulic Fluid
Normal use (>32° F [0° C]) ISO #46 ISO #46 ISO #46
Low Temp. Use (<32° F [0° C]) ISO #32 ISO #32 ISO #32
Extreme Temp. Use (<0° F [-17° C]) ISO #15 ISO #15 ISO #15
Lift System One Single Stage Lift Cylinder One Single Stage Lift Cylinder Two Single Stage Lift Cylinders
Lift Speed Raise: 40 sec. Lower: 60 sec. Raise: 45 sec. Lower: 65 sec. Raise: 45 sec. Lower: 65 sec.
Platform Leveling 8.5° (12 in. [.3m]) Side/Side, 6° (12 in. [.3m]
Fore/Aft
8.5° (12 in. [.3m]) Side/Side, 6° (12 in. [.3m]
Fore/Aft
8.5° (12 in. [.3m]) Side/Side, 6° (12 in. [.3m]
Fore/Aft
Power Source Diesel or Gasoline 20 HP Kubota, 3 Cylinder,
Water Cooled
Diesel or Gasoline 20 HP Kubota, 3 Cylinder,
Water Cooled
Diesel or Gasoline 20 HP Kubota, 3 Cylinder,
Water Cooled
Drive Control Proportional Proportional Proportional
Control System Smooth one-hand Joystick Smooth one-hand Joystick Smooth one-hand Joystick
Horizontal Drive 2WD: 2 Wheel, Hyd. Motors
4WD: 4 Wheel, Hyd. Motors 2WD: 2 Wheel, Hyd. Motors
4WD: 4 Wheel, Hyd. Motors 2WD: 2 Wheel, Hyd. Motors
4WD: 4 Wheel, Hyd. Motors
Air Filled Tires 10-16.5 NHS 8 Ply, 50psi. [3,4 bar] 10-16.5 NHS 8 Ply, 50psi. [3,4 bar] 10-16.5 NHS 8 Ply, Foam Filled
Parking Brakes Two, Spring Applied, Hydraulic Release,
Multiple Disc
Two, Spring Applied, Hydraulic Release,
Multiple Disc
Two, Spring Applied, Hydraulic Release,
Multiple Disc
Turning Radius (inside) 48 in. [1,22 m] 48 in. [1,22 m] 48 in. [1,22 m]
Maximum Gradeability: 2WD: 30% [16,7°] 4WD: 35% [19,2°] 2WD: 30% [16,7°] 4WD: 35% [19,2°] 2WD: 30% [16,7°] 4WD: 35% [19,2°]
Wheel Base 115.75 in. [2,94 m] 115.75 in. [2,94 m] 115.75 in. [2,94 m]
Guardrails 43.5 in. [1.1 m] high, Fold Down with gate. 43.5 in. [1.1 m] high, Fold Down with gate. 43.5 in. [1.1 m] high, Fold Down with gate.
Toeboard 6 in. [152 mm] High 6 in. [152 mm] High 6 in. [152 mm] High
*S
PECIFICATIONS
TEL: (800) 559 926-5438 or (559) 891-5200
FAX: (559) 896-9012
PARTS: (888) UR-PARTS
PARTSFAX: (559) 896-9244
1775 Park St., Selma, CA 93662
http://www.upright.com
FOR MORE INFORMATION
Local Distributor:
067903-004
12/99 D
