Table 9 — Fan Rpm at Motor Pulley Settings*
*Approximate fan rpm shown.
†Indicates standard motor and drive package.
**Indicates high-static motor and drive package.
Table 10 — Accessory/FIOP Electric Heaters Static Pressure* (in. wg) — 549B090-120
LEGEND
FIOP — Factory-Installed Option
*The static pressure must be added to external static pressure. The sum and the evaporator
entering-air cfm should then be used in conjunction with the Fan Performance tables to deter-
mine blower rpm and watts.
Table 11 — Accessory/FIOP EconoMi$er IV Static Pressure* (in. wg)
LEGEND
*The static pressure must be added to external static pressure. The sum and the evaporator entering-air cfm
should be used in conjunction with the Fan Performance tables to determine indoor blower rpm and watts.
GENERAL FAN PERFORMANCE NOTES
1. Extensive motor and electrical testing on these units ensures that the full
range of the motor can be utilized with confidence. Using fan motors up
to the ratings shown will not result in nuisance tripping or premature
motor failure. Unit warranty will not be affected. For additional informa-
tion on motor performance refer to Fan Motor Performance, Table 8.
2. Values include losses for filters, unit casing, and wet coils. See Tables 10
and 11 for FIOP/accessory static pressure information.
3. Use of a field-supplied motor may affect wire sizing. Contact your Bryant
representative to verify.
4. Interpolation is permissible. Do not extrapolate.
UNIT
549B MOTOR PULLEY TURNS OPEN
0 1 /
2
1 1 1 /
2
2 2 1 /
2
3 3 1 /
2
4 4 1 /
2
5 5 1 /
2
6
090† 950 930 905 885 865 840 820 795 775 750 730 — —
090** 1080 1060 1035 1015 990 970 950 925 905 880 860 — —
102† 1085 1061 1036 1012 987 963 938 914 889 865 840 — —
102** 1080 1058 1036 1014 992 970 948 926 904 882 860 — —
120† 1080 1060 1035 1015 990 970 950 925 905 880 860 — —
120** 1130 1112 1087 1062 1037 1212 987 962 937 912 887 862 830
COMPONENT
CFM
2250 2500 3000 3500 4000 4500 5000 5500 6000 6250
1 Heater Module 0.02 0.03 0.05 0.07 0.08 0.10 0.12 0.14 0.16 0.17
2 Heater Modules 0.03 0.05 0.07 0.09 0.12 0.14 0.16 0.19 0.21 0.20
COMPONENT
CFM
2250 2500 2750 3000 3250 3500 3750 4000 4250 4500 4750 5000 5250 6250
Vertical EconoMi$er IV 0.06 0.075 0.09 0.115 0.13 0.15 0.17 0.195 0.22 0.25 0.285 0.325 0.36 —
Horizontal EconoMi$er IV — 0.1 0.125 0.15 0.18 0.21 0.25 0.275 0.3 0.34 0.388 — — —
FIOP — Factory-Installed Option
