14
COD. 193553058 - v.2 - UPD 060404
33333 - SAFETY - SAFETY - SAFETY - SAFETY - SAFETY
Observe all the following safety rules. They are of the maximum importance for your own safety and the safety of
others. In addition to the indications in this chapter, observe also the prescriptions in all other sections of the manual.
DO NOT TAMPER WITH THE PROTECTIONS AND SAFETY DEVICES AND DO NOT MODIFY THE PUMP IN ANY
WAY TO AVOID CREATING POTENTIALLY HAZARDOUS SITUATIONS FOR WHICH THE OPERATOR OR
SERVICE TECHNICIAN IS UNPREPARED.
REMOVING OR TAMPERING WITH ANY OF THE SAFETY DEVICES ON THE PUMP AUTOMATICALLY
INVALIDATES THE WARRANTY AND ABSOLVES THE MANUFACTURER FROM ALL LIABILITY.
l The pump and the machine on which the pump is installed must be used exclusively by people over 18 years of
age who have read this manual and have a thorough knowledge of the machine and the pump.
l The pump may be used by persons over the age of 16 provided they are supervised by an adult.
l The work area must be kept clear of obstructions so that the pump can be operated in safe conditions.
Pay attention to falling objects which could strike the pump treadle and set the pump into operation.
l The work area must be kept clean and the floor must bear no traces of oil, grease and slippery or corrosive
substances of any type.
l Keep the pump well clear of heat sources, naked flames and sparks. Maximum operating temperature of the pump
is 50° C.
l Work clothes must be close fitting and buttoned up. Wear the protective clothing stipulated in the place where the
pump is installed.
l Do not disconnect the air supply hose or the hydraulic oil hose until you are sure that the circuits are not
pressurized.
l When connecting the pump follow the prescriptions in chapter 5 “Installation and start-up” and always use certified
hoses and couplings.
l If the pump develops a fault, do not attempt to repair it unassisted. Disconnect the compressed air supply, switch
off the machine to which the pump is connected and call the maintenance technician.
l Do not arbitrarily move the pump to different locations. The pump must be used in the position designated by the
manufacturer of the machine to which it is connected.
4 - TECHNICAL SPECIFICA 4 - TECHNICAL SPECIFICA 4 - TECHNICAL SPECIFICA 4 - TECHNICAL SPECIFICA 4 - TECHNICAL SPECIFICATIONS TIONS TIONS TIONS TIONS
(*) Dif
ferent connection types
are available on request
(•) With 7 bar compressed air supply pressure
RECOMMENDED OIL TYPES RECOMMENDED OIL TYPES RECOMMENDED OIL TYPES RECOMMENDED OIL TYPES RECOMMENDED OIL TYPES
MOBIL DTE 11 - SHELL TELLUS OIL T 15 - CASTROL HYSPIN AWH15 - or equivalent
Model AHP 2-1D-502 AHP 2-1D-702 AHP 2-1D-505 AHP 2-1D-705
Air inlet pressure (bar)• 2.8 - 10 bar (*)
Maximum working pressure (bar)• 500 700 500 700
Maximum flow rate (litres/min.)• 1.4 0.8 1.4 0.8
Air connection (standard)* 1/4" G
Reservoir capacity/ usable capacity
in horizontal position (I) 2.4 / 2.1 5 / 4.5
Reservoir capacity/usable capacity
in vertical position (l)
2.2 / 1.53.5 / 2
Dimensions (mm) Pump dimensions are shown on page 2, figs. 1 and 2
Noise level 75 dB(A) / 1m
Oil connection (standard)* 1/4" G
Max. weight (kg) without oil 5.7 10.05
