Replacement parts (tcd-2) – Bunn TCD-2 User Manual
Page 15
ITEM
PART NO.
QTY.
DESCRIPTION
15
* Indicates the part number listed is for reference only. See DESCRIPTION for possible service replacement.
30
37786.0001
2
Plate, Fitting Retainer
38044.0000
2
Screw, Plastite #6 x .375"
31
32631.0000
1
Fitting, Barb .25"
32
32631.0001
1
Fitting, Barb .375"
33
32849.0001
2
O-ring
34
37487.1000
1
Venturi Mixer (Includes item 39)
35
37691.0000
1
O-ring
36
37486.0000
1
Adjustment Screw, Venturi
37
03093.0001
2
Wing Nut, Faucet
01268.0000
2
Chrome Nut, Faucet Union (Optional)
38
32852.0000
2
O-ring
39
01221.0001
2
C-Ring, Faucet Shank
40
03260.0004
2
Faucet Assy, Black Plastic Body (Includes items 41 thru 47)(Refer to page 18 for
important ordering information)(See item 73)
03260.0005
2
Faucet Assy, Chrome Body (Includes items 41 thru 48)(See item 73)
41
29163.0007
1
Handle, Faucet
42
29165.0002
1
Bonnet, Faucet
43
00601.0001
1
Spring Faucet
44
37715.0000
1
Collar, Spring (Refer to item 72)
45
29164.0000
1
Stem, Faucet
46
00600.0001
1
Seat Cup, Faucet (Refer to item 72)
47
35758.0002*
1
Faucet Body, Black Plastic (Order item 40)
35206.0000*
1
Faucet Body, Chrome (Order item 40)
48
38473.0000
1
Insert
49
- - - - - - - -
2
Tube, Silicone .25" ID x 36.0" (If for first replacement, order item 75)
37720.0003*
2
Tube, Silicone .375" ID x 36.0" (Order item 69)
50
26443.0000
2
Reducer, Barb .375" x .25"
34644.0000
2
Connector, Barb .375" x .375"
51
12422.0001
12
Clamp, Hose .59"/.66"
52
37720.0000*
2
Tube, Silicone .375" ID x 3.0" (Order item 70)
38295.0000*
2
Tube, Silicone .375" ID x 36.0" (Order item 70)
53
37744.0000
2
Tube, Concentrate Bottle .25"
37744.0001
2
Tube, Concentrate Bottle .375"
54
34093.0000
1
Lid, Reservoir
55
38029.1000
1
Drip Tray Assy (Includes items 56 & 57)
56
03229.0000
1
Drip Tray Cover
57
03207.0004
1
Drip Tray
REPLACEMENT PARTS (TCD-2)
34106.1 112106
(continued)
For use with .375" BIB adapter
Optional
