16
6.4 Unrolling
6.5 Coiling
To unroll, pull at the extension hoses until the required length has been unrolled from the
hose reel.
CAUTION!
For unrolling the hose from the hose reels, the parking brake must fi rst of all be
released. This prevents damage to the reel and the hoses.
REMARK:
We recommend the use of the hand crank for coiling the hose!
- First of all, put the hand crank onto the shaft of the hose reel.
- Release the parking break.
- Aligning the hose simplifi es the coiling of the hose.
- Now, you can turn the hand crank to coil the extension hose pair.
Ensure that the extension hose pair is always properly coiled on the hose drum.
This is usually guaranteed by guiding the extension hose pair with your hand during the
coiling process.
- Finally, you must activate the parking brake of the hose reels again and remove the crank
handle.
- In the case of the single hose reel the crank should be fl apped in again for safety reasons.
7. Dismantling the equipment / deactivation following
operation
7.1 Equipment
7.2 Hydraulic unit
7.3 Hoses
If the hose reel is to be disconnected from the unit and the equipment, please proceed as
follows:
On the side of the equipment:
Decouple the hoses as described in chapter “Connecting the equipment”.
Ensure that you put the dust protection caps back on to the mono-couplings.
On the side of the hydraulic unit :
Decouple the hoses as described in chapter “Connecting the equipment”.
Ensure that you put the dust protection caps back on to the mono-couplings.
Basically, all used equipment must be safely stored following deactivation.
Once work has been completed, the equipment is to be reset to its basic position.
Upon completion of work, the unit must be deactivated.
