11
5. Connecting the equipment
5.1 On the side of the hydraulic unit
5.2 On the side of the equipment
REMARK:
Different couplings than mono-couplings, like quick-disconnect-couplings, are
possible when using available adapter kits. Also the direct screw connection
into the pump connection block of the power unit is possible. The adapter kits
can be ordered via the LUKAS optional equipment.
There are “short” hoses on the side of the unit: they are connected to the pump unit.
The extension hose pairs are on the side of the equipment: they are connected with the
equipment by means of couplings. The combination female and male coupling ensures an
unmistakable connection.
WARNING / CAUTION!
Before connecting the equipment you have to pay attention that all
used components
are suitable to the max operation pressure of
the pump unit
! In the case of doubt you have to inquire LUKAS
directly!
