3
6 7 8
1 4 5
3
2
6 7 8
2 1 4 3 5
1 Star grip
2 Main switch
3 LED indication panel
4 Handle
5 Socket 24 V
6 Blade arms
7 Central bolt with
self-locking nut
8 Cylinder body
7 8
2 1 5
3
4
6
9
LKE 50 / LKE 51
LKE 70
LKE 55
1 Star grip
2 Main switch
3 Quick-change accu.
4 Release button for
quick-change accu.
5 Handle
6 Ventilation slits
7 Blade arms
8 Central bolt with
self-locking nut
9 Cylinder body
