14
15 Technical data
*Weight (including oil filling, handle and carrier belt):
Oil specifications: delivered with mineral oil HLP 10 DIN 51524 (closed oil cycle).
Specifications according to NFPA 1936:
15.1 Maximum cutting performance of LKE
The following materials (according to EN 13204, S235JR) can be cut :
With hollow profiles outside dimensions x wall thickness.
Max. Dimensions of Material
Type of Form of LKE 50 LKE 51 LKE 70 LKE 55
material material mm mm mm mm
21 27 26
60 x 5 100 x 10 80 x 8
Steel 40 x 40 x 4 55 x 55 x 4 55 x 55 x 4
42.4 x 2.6 76.1 x 3.2 60.3 x 2.9
50 x 25 x 2.5 80 x 40 x 3 60 x 40 x 3
Type LKE55
Cutting class A5 B5 C5 D7 E7
LSF (kN / lbs) 23.4 / 5,250
HSF (kN / lbs) 26.3 / 5,910
LPF (kN / lbs) 30.7 / 6,910
HPF (kN / lbs) 35.2 / 7,910
Type LKE 50 LKE 51 LKE 70 LKE 55
Order no. 84150/7010 84150/7040 84150/7034 84150/7060
Dimensions l x w x h (mm) 720x230x134 742x233x134 860x270x173 807x200x267
Operating pressure (MPa) 67 58 63
Weight* (kg) 15.8 15.2 22.8 15.6
Weight without handle and carrier belt (kg) 15.2 14.6 -- --
Opening time without load (sec) 6 8 7 8
Closing time without load (sec) 6.5 8.5 9 9
Max. distance between tips (mm) 200 256 300 316
Spreading force 25 mm from tips (kN) 26 ... 30 32 ... 37 28 ... 35
Pulling force with chain set KSV 7 (kN) 25 ... 27 24 ... 27 -- --
Pulling distance with chain set KSV 7 (mm) 220 285 -- --
Pulling force with chain set KSV 8 (kN) -- 33 ... 39 26 ... 33
Pulling distance with chain set KSV 8 (mm) -- 305 320
Cutting class according to EN 13204 D D G E
Remark:
The cutting performance is indicated for perfect condition of the blades (new or perfectly reground),
central bolts tightened in accordance with the specifications and correct handling (see item 9) of
the devices.
